.308 Camshaft & Flywheel 3.308"Connecting Rod For Hemi Predator 212cc Kart

Overview

This is a high-performance, value-oriented racing upgrade package designed for builders seeking strong high-RPM power output with a cost-effective component setup for Hemi Predator engines.

Built around a .308 high-lift Hemi camshaft, it delivers aggressive valve timing, extended duration and improved airflow for maximum top-end performance. Supports a target operating range of 8200–8400 RPM, suitable for competitive kart racing and high-performance recreational builds.

Unlike premium billet racing configurations, this version uses a durable cast aluminum (die-cast) performance flywheel, providing a more affordable solution while still improving throttle response and engine acceleration over stock components.

✅ Fitment

• • Designed for 212cc Hemi Predator engines
• • Compatible with 196cc clone and GX200 platforms
• • Recommended for modified high-performance racing applications

🚀 Premium Performance Features

1. Aggressive .308 High-Lift Camshaft

• Engineered for aggressive valve timing, extended duration and improved airflow for maximum top-end performance.
• Optimized for modified Hemi engines with a target operating range of 8200–8400 RPM.

2. Cost-Effective Cast Aluminum Flywheel

• Durable die-cast aluminum construction as an affordable alternative to billet racing flywheels.
• Delivers improved throttle response and faster engine acceleration compared to stock components.

3. Reinforced Rotating Assembly & Piston

• 3.308” performance connecting rod + bearing set for reinforced bottom-end strength.
• 70mm flat-top piston kit (rings + wrist pin) increases compression ratio for stronger torque and acceleration.

4. Complete Valvetrain, Sealing & Ignition Support

• 26lb valve springs ensure stable valve control at high RPM.
• F7TC performance spark plug delivers stable ignition under sustained load.
• Full Hemi gasket & seal kit provides complete rebuild-level engine sealing integrity.

📐 Camshaft Specifications (.308 Hemi Profile)

Recommended Class: Modified Racing
Target RPM Range: 8200–8400 RPM

• • Intake Lift: .308”
• • Exhaust Lift: .308”
• • Duration @ .050”: 244.2° Intake / 244.6° Exhaust
• • Lobe Separation Angle: 108° / 108°
• • Valve Spring Pressure: 32 lb (IN / EX)
• • Valve Lash (IN / EX): .003”
• • Ignition Timing Recommendation: 34° BTDC

Cam Timing Events

• • Intake Open: 53.5° BTDC
• • Intake Close: 91.0° ABDC
• • Exhaust Open: 91.0° BBDC
• • Exhaust Close: 55.1° ATDC
• • Lift: .308” / .308”

This camshaft delivers strong high-RPM power delivery and extended top-end performance when paired with upgraded valvetrain components.

📦 Included Performance Components

• 1 x .308 Hemi Performance Camshaft

• 1 x 3.308” Performance Connecting Rod + Bearing Set

• 2 x 26lb Valve Springs

• 1 x Cast Aluminum Performance Flywheel (Hemi / 212 Compatible)

• 1 x F7TC Performance Spark Plug

• 1 x Complete Hemi Gasket & Seal Kit

• 1 x 70mm Flat-Top Piston Kit (rings + wrist pin)

• 1 x Magnetic Drain Plug Set (M10x1.25)

🏁 Performance Benefits

• • Strong high-RPM power delivery (8200–8400 RPM range)
• • Improved throttle response vs stock engine setup
• • Increased compression for better acceleration
• • Stable valvetrain performance with 26lb springs
• • Cost-effective cast flywheel performance upgrade
• • Reinforced bottom-end durability for modified builds
• • Balanced setup for competitive and recreational racing use

📝 Important Notes

This is a value-oriented high-performance kit using a cast aluminum flywheel instead of billet or machined racing components. It is designed to provide strong performance gains while maintaining cost efficiency.

Professional installation experience is recommended. Engine clearancing may be required depending on configuration.
